Honda TRX420FM1 Fourtrax 2/4WD

$14.64 $24.89
Description Classification    Utility work ATV Engine    420cc liquid cooled, wet-sump, longitudinally mounted OHV 4-stroke single cylinder Carburation    PGM-FI 34mm Ignition   Full transistorized with electronic advance Starter   Electric Transmission    Manual foot-shift; 5 speed and reverse Drive   Front and rear driveshafts with TraxLok™ and torque-sensing front differential. Front Suspension   Independent double-wishbone; 170mm travel Rear Suspension   Swingarm with single shock; 170mm travel Power Steering  No Front Brakes   190mm dual hydraulic discs Rear Brake    160mm sealed mechanical drum Front tyres   24 x 8-12 Rear tyres   24 x 10-11 Fuel Capacity (l)   14.9L, incl. 4.9L reserve. Bore x Stroke (mm)   86.5 x 71.5 Dimensions – Length (mm)   2100 Dimensions – Width (mm)   1200 Dimensions – Height (mm)   1170 Wheelbase (mm)   1270 Seat Height (mm)   855 Ground Clearance (mm)   180 Towing Capacity (kg)   384 Front Rack Capacity (kg)  33 pounds Rear Rack Capacity (kg)  66 pounds
