Description Classification  Utility work ATV Engine 420cc liquid cooled, wet-sump, longitudinally mounted OHV 4-stroke single cylinder Carburation  PGM-FI 34mm Ignition  Full transistorized with electronic advance Starter   Electric Transmission   Automatic ESP push-button; 5 speed and reverse Drive   Front and rear driveshafts with TraxLok™ and torque-sensing front differential. Front Suspension  Independent double-wishbone; 170mm travel Rear Suspension  Swingarm with single shock; 170mm travel Power Steering  No Front Brakes  190mm dual hydraulic discs Rear Brake  160mm sealed mechanical drum Front tyres  24 x 8-12 Rear tyres  24 x 10-11 Fuel Capacity (l)   14.9L, incl. 4.9L reserve Bore x Stroke (mm)   86.5 x 71.5 Dimensions – Length (mm)  2100 Dimensions – Width (mm)   1200 Dimensions – Height (mm)   1170 Wheelbase (mm)   1270 Seat Height (mm)  855 Ground Clearance (mm)   180 Towing Capacity (kg)  384 Front Rack Capacity (kg)  33 pounds Rear Rack Capacity (kg)  66 pounds
